Model: 3G Newport
BLACK semi-MATTE powdercoated*
Material: Aluminium
Possible wheels 26" with rims up to 80 mm wide + tire up to 26 x 3,45
Bottom bracket: oversized FATBIKE-BSA 100 mm wide shell
Head tube 200 mm
for 1 1/8" forks with 25-30cm steerer tube
For Seat post of 27,2 mm
Rear contains derailleur holder + IS disc brake mount
Width of rear hub / dropouts / chain stays: OLD 135 mm
Dimensions:
seat -> head tube: ~ 645 mm / 25,4 inches
seat -> bottom bracket: ~ 505 mm / 20 inches
Frame weight: about 2,7 kg
Chainguard mount points distance 455 mm
The frame has holes for inserting the brake cable inside, the set includes 2 plastic hole covers
BOTTOM AXLE CLEARLY FORWARD FROM THE SADDLE POSITION
ENABLES YOU EASY PLACING YOUR FEET ON THE GROUND
WITH A COMFORTABLE RIDING POSITION AND A STRAIGHT KNEE WHILE PEDALING
